Description
 |
 |
 |
 |
FEATURES:
The GRL 350 HV + LR 30 combines precision, versatility, and durability for professional-grade leveling and alignment. Designed for both horizontal and vertical applications, it delivers highly accurate results on large-scale construction, surveying, and grading projects. The included LR 30 laser receiver extends the working range up to 350 meters, ensuring reliable detection even in challenging conditions.
Featuring dual-axis slope capability, electronic self-leveling, and selectable rotation speeds, the GRL 350 HV adapts to complex tasks with ease. Its robust IP56-rated housing protects against dust and water, while the compact, ergonomic design makes setup fast and effortless. The system comes complete with mounting accessories, red laser glasses, a target plate, and a durable carrying case — everything you need to measure with confidence and efficiency.
- Versatile - Horizontal and vertical manual dual slope function enable change in grade in two-axis application
- Flexible - Variable-speed and Scan-angle selection allow optimum usability at different lighting conditions
- Robust - IP 56 rated to protect against dust and water for tough jobsite conditions, with shock-warning function to alert error due to vibration
SPECS:
- Laser diode: 630 – 650 nm, < 5mW
- Operating temperature: -10 – 50 °C
- Storage temperature: -20 – 70 °C
- Laser class: 3R
- Working range, value: 60 m
- Working range with receiver: 350 m (diameter)
- Accuracy: ± 1.5 mm at 30m horizontal, ± 3.0 mm at 30m vertical
- Self-levelling range: ± 5° (8%)
- Levelling time: 30 s
- Dust and splash protection: IP 56
- Rotation speed: 0/150/300/600 min-¹
- Power supply: 2 x 1.5 V LR20 (D)
- Operating time (max.): 30 h
- Weight, approx.: 1.8 kg
- Colour of laser line: red
- Color of plumb points: red
- 6 years warranty
INCLUDES:
- Laser Receiver LR 30 Professional
- Bracket
- Universal Mount
- Laser Viewing Glasses (Red)
- Laser Target
- 2 x 1.5V LR20 Battery (D)
- 9V Block Battery
