Features:
- Compact and lightweight, suitable also for one-handed transport
- Sliding function for wide work pieces
- Robust die-cast aluminium design for highest demands
- Effective dust extraction via integrated dust scoop
- Fast and precise setting of common angles using stop points
- Laser for exact display of the cutting line
- Infinitely extendable table width extension, removable to put long panels, slabs etc. underneath
- Bright LED work light for illumination of the cutting line
- High sliding rear fence profiles for safe sawing
- Material clamp for secure fixing of the work piece from the top or front
- Depth stop for easy creation of grooves
- Saw head can be inclined to the left, with additional angle range for undercuts
- All scales and operating elements are visible from the working position and can be operated intuitively
- Easy saw blade change by means of spindle lock: no dismantling of the pendulum protective cover required
- Supplied with carbide saw blade (40 teeth), 2 table length extensions, length guide, material clamp, tool for saw blade change, cable winder and chip collection bags
Specifications:
- Dimensions: 760mm L x 475mm W x 340mm H
- Maximum Cutting Width at 90°/45°: 305mm / 205mm
- Maximum Cutting Depth at 90°/45°: 65 mm / 36 mm
- Maximum Cross-Section of The Workpiece
- Straight Cut 90°/90°: 305 x 65 mm
- Double Mitre 45°/45°: 205 x 36 mm
- Turntable Setting Left/Right: 47 ° / 47 °
- Saw Blade Tilt Left/Right: 47 ° / 2 °
- Saw Blade Size: Ø 216 x 30 mm
- Rated Input Power S1 100%: 1,200 W
- Rated Input Power S6 20%: 1,500 W
- Revolutions at Rated Load: 3,750 /min
- Cable Length: 2 m
- Weight: 13.5 kg
