Description
Features
- Fast, Clean Bends - Ideal for high-volume production
- Multi-Bar Processing - High-efficiency bending
- Bending Capacity - 6-46mm rebar (D500N)
- Advanced Digital Controls - Digitally preset multiple bend angles + built-in bend counter
- Bidirectional Bend Table - Enhanced flexibility and efficiency
- Heavy-Duty Three-Phase Motor - Built for continuous, high-output performance
- Foot Pedal Control - Flexible, ergonomic, and operator-safe
- Safety-First Design - Interlocked guards and door sensors
- Precision, Speed & Industrial Durability - Production-grade performance including industrial frame for maximum durability and long service life
- European Engineering, Local Support - Built for Australia with parts and full servicing in Australia
- Features and specifications are approximate only. Refer to product datasheet for details.
Specifications
- Production-grade heavy-duty performance with a rated bending capacity of 46mm diameter rebar (650MPa)
- Max Diameter of Bar & No. of Bars: 46mm - 1 Bar / 34mm - 2 Bars / 22mm - 3 Bars
- Average Bend Cycle Speed: 8 RPM
- Rated Voltage and Frequency: 400-415V 3~ 50Hz
- Rated Power: 5.5 Kw
- Rated Current: 11.6 A
- Number of Phases: 3
- Full Load Motor Speed: 1400 RPM
- Net Weight: 775 kg
- Machine Dimensions (L— W— H): 90cm x 130cm x 95cm
- Made in Italy
- 12 Months Warranty
Inclusions
- Foot Pedal
- Safety Guard
- Squaring Arm Set
- Large Diameter Arm*
- Multiple Bend Pin/Bushing Diameters: 25/42/60/80/100/120/150/192*/240*mm *Use with Large Diameter Arm (Custom Diameter Bushings Available)
- Optional Accessories: Stirrup/Ligature + Spiral/Rebar Ring Forming Tools
- Priority Service - Local support, parts, and service from RAPIDTOOL
