Features:
- Industry-first 7-year warranty*
- Dual-Purpose Power Source Technology allows the 290MST
- to be used as a stand-alone compact / portable unit, or
- fitted with separate wire feeder unit
- Max MIG output 290A @ 55% duty cycle
- Dual Input Modes to allow use with either 240V 15A plug
- (fitted) or 240V 32A plug (optional)**
- Manual or Synergic MIG controls (enter material type &
- thickness and machine will set parameters automatically)
- Job Save - store custom settings for up to 20 jobs
- Geared 4-Roll Wire Drive System - for super reliable wire feeding
- Takes 5kg (D200mm) or 15kg (D300mm)spools
- Spool Gun Ready
- Generator Compatible - min 15kva, ideal 20+kva
- MIG functions & adjustments include: Inductance, Soft
- Start, Burnback, Pre-Gas Time, Post-Gas Time, 2T/4T
- Trigger, Spot/Stitch Time
- Stick/MMA functions & adjustments include: Hot-Start %, Arc-Force %
- TIG functions & adjustments include: Trigger & Remote
- Amperage Control on the torch, Post-Gas Time, Slope-Up Time
Technical Specifications:
- MIG welding <290A with solid mild steel (0.8-1.2mm), gasless (0.8-1.2mm), flux-cored with gas (1.2mm), stainless-steel (0.8-1.2mm), aluminium (0.9-1.2mm), & bronze/brazing (0.8-1.2mm) wires
- Stick/MMA welding <270A with most types of common electrodes (2.0-4.0mm), including steel, stainless-steel, hardfacing & more
- TIG welding <290A (DC lift-arc) of steel, stainless, copper & chrome molly up to 5-6mm max thickness (NOT suitable for TIG welding of aluminium)
Inclusions:
- MIG Torch 4m BZL 36
- Earth Lead 4m
- Gas Regulator
- Driver Rollers for 0.9/1.2mm steel/solid wires & 0.9/1.2mm flux-cored/gasless wires
- Power Input Lead (4mm2) with heavy-duty 240V 15A plug fitted**
- Separate Wire Feeder Packages include SWF114 wire feeder unit with 8m interconnecting cables
