Description
Features
- Swivel head enables from 0° to 60° mitre cuts
- Dual mode operation
- Trigger switch with manual down feed for small quick cuts
- Control panel with fully adjustable hydraulic down feed & automatic shut-off at end of cut, for cutting larger material
- Incorporated recirculating coolant system
- Brass chip brush to help prevent blade breakage
- Adjustable material stop for repetitive production
- Safety emergency stop switch
- 12 months warranty
- Comes complete with stand & blade
Specifications
- Motor: 1.5hp Three Phase (415V)
- Blade Speed: 2 Speed 36 / 72 mpm
- Blade Size: 27mm x 0.9mm x 2460mm
- Bed Height: 840mm
- Weight: 216kg
- 90° Cutting Capacity: Round: 220mm | Square: 215mm | Rectangle: 260 x 110mm
- 45° Right Cutting Capacity: Round: 150mm | Square: 145mm | Rectangle: 155 x 110mm
- 60° Right Cutting Capacity: Round: 90mm | Square: 85mm | Rectangle: 95 x 80mm
