Cigweld BlueVenom SiC XF250 AC/DC TIG Welder - W1300250

Key features

• Lightweight and Powerful: 16.8Kg and 250A
• Stick and Stick with Pulse: 200A @ 25%
• HF AC/DC TIG: 250A @ 33%
• Plate Thickness Control with Joint Type Selection (Quickset)
• 9 different AC Waveforms and AC+DC mode
• TIG Cold Weld & TIG DC SuperPulse mode
• Plate Thickness Control with Joint Type Selection (Quickset)
• Compatible with CoolVenom 4ltr Cooler
• SiC Inverter Tech for the best TIG performance
• IP23S Coolant Proof, PFC and SiC Technolies
• 100x Memory provisions, 5" LCD Touch Screen Display

Specifications

• Power Supply Voltage: Single Phase – 15Amp Plug230V +/- 10%
• Australian Standards: AS 60974.1:2020
• Nominal Supply Frequency: 50/60Hz
• TIG Duty Cycle @40% : 250A @ 33%, 18.0V
• Minimum Generator Requirement: 8.5 kVA (0.8 Power Factor at Max Amps)
• Amperage Range: TIG: 10A – 250A STICK: 10A – 200A
• TIG Duty Cycle @40% : 250A @ 33%, 18.0V
• Stick Duty Cycle @40% : 200A @ 25%, 18.0V
• VRD on Stick
• Protection Class: IP23S

Inclusions

• DimexElite 8m 26F ‘Flex Head’ TIG Torch with Trigger Button and Remote Current Control
• TIG Consumables kit
• 250A Twist lock Electrode Holder with 3m Lead
• BlueJet Regulator/Flowmeter
• 3m Quick Connect Gas Hose
• 250A Earth Clamp with 3m Lead
• BlueJet Regulator/Flowmeter
• Operating Manual

Warranty & Returns

• 5 - Years
